1.4 ton, Kubota Diesel Engine Mini & Small Excavator w/ Side Swing Boom | AGT-NT18

Compact and reliable, the 1.4-ton AGT Mini Excavator offers a 6.96-foot digging depth, air conditioning, a side-swing feature, and an enclosed cab for comfort and dust-free operation, making it ideal for farms, gardens, parks, and tight spaces.

In Action Video

Dimension

• Operating Weight: ~1,400 kg (3,086 lbs)
• Overall Length: 3,300 mm (130 in)
• Overall Width: 1,100 mm (43 in)
• Overall Height: 2,300 mm (91 in)
• Track Width: 230 mm (9 in)
• Track Length: 1,500 mm (59 in)
• Tail Swing Radius: 650 mm (25.6 in)

Working Range

• Max Digging Depth: 1,850 mm (72.8 in)
• Max Digging Height: 3,050 mm (120 in)
• Max Dumping Height: 2,050 mm (80.7 in)
• Max Reach at Ground: 3,400 mm (133.8 in)
• Dozer Blade Width: 1,100 mm (43 in)
• Dozer Blade Height: 210 mm (8.3 in)
• Blade Max Lifting Height: 220 mm (8.6 in)
• Blade Max Drop Depth: 280 mm (11 in)

Features

• Side Swing Boom
• Pilot Control

Engine

• Engine Brand: Kubota
• Fuel Type: Diesel
• Model: D902-E4B
• Rated Power: 16 kW (21.5 HP)
• Displacement: 898 cc
• Fuel Capacity: 17 L (4.5 gal)
• Fuel Consumption: ~1.1–1.3 L/hr
• Hydraulic Flow Rate: 23 L/min (6.1 GPM)
• Hydraulic Pressure: 20 MPa (2,900 PSI)
• Hydraulic Tank Capacity: 16 L (4.2 gal)
• Battery: 12V, 45–60Ah
